INSTITUTO CERVANTES BXL
headquarters refurbishment
Brussels, Belgium
1/8
TEXT

Everything is pre-existing, recycled or, if new, mobile.

Preexisting, apart from the structure and the enclosure, we found interesting elements to preserve; the temptation would be to empty everything and start over, but many installations and even finishes could be preserved and integrated into a new concept.

Recycled, in the mature market of Brussels it is possible to find recycled materials of high quality and benefits at very competitive prices. In addition, the Institute had materials from the previous headquarters (and other centres) that can be easily incorporated.

Mobile, so that the investments in new materials of equipment can be reused in the future regardless of functional or strategic changes.

2/8
TEXT

The activities allocated in this floor are visible from the street as a way to highlight its public essence. A domestic library, a coffee hall, a multifunctional space with stands or the information displayed on the monitors.

A pixelated sky ceiling that encloses all the installations machines, stablishes a direct dialogue with the language use to solve the stair that connects the hall in the second floor that gives access to the classrooms.

3/8
TEXT

The ground floor is a single and continous space. There are lines of vision that cross the space from one side to the other. The light comming through the windows of a façade can be seen from the other one.

4/8
TEXT

However, there are clearly separate enclosures and routes; the library has a defined and controlled access point, but when we go inside it, we find places to rest, windows, points of visual contact with the rest of the program. Inside of the library route, the most sheltered angle hosts the children’s library area. Then, at halfway a ramp rise above the grount finishing the tour on a reading room furnished as a domestic space surrounded by books, but at the same time serving as a storefront and a stage.

5/8
TEXT

The central space accommodates complementary and temporary functions, framed by curtains or light furniture, which also allows to use it as a classroom for teaching activities. It is a space between classrooms, used for waiting to start a class, informal talks, to manage enrollment periods, and also for extracurricular activities.

6/8
TEXT

The velvet curtains work acoustically, while giving this space a theatrical character that facilitates the role play, much needed for language learning.

7/8
8/8
TEXT

The circle is coated with recycled PETT felt, which is acoustically absorbent, and allows the communication of teachers and students to be sharp and effective. The coloured felt works also as a contrasting background that allows us to gladly reuse the existing chairs in the previous headquarters

1/8
TEXT

One of the major challenges of the project was to combine at the ground floor level the required flexibility for a multifunctional and public space, and allowing at the same time the possibility to locate 30.000 books of the library. The system proposed to solve this issue was a three-dimensional version of the Cervantes Institute Logo. Orthogal geometries created by thick red lines which limit undefined spaces.

2/8
3/8
4/8
5/8
TEXT

We have observed that the teaching system used by the Instituto Cervantes requires a circle arrangement of students. We also take account that this circle arrangement conflicts with the square perimeter of the usual spaces for this use. Therefore, we plan to mark the circle in the classrooms with an element of simple construction. In the interstices suitably chosen plants are placed to help clean the atmosphere of the room.

6/8
7/8
8/8
CASA AMOR
WEEKEND HOUSE
MADRID, SPAIN
1/6
TEXT

A little weekend house in the heart of la Moraleja.

2/6
TEXT

Lost in the highest part of a holm oak forest. It’s a treehouse. In summer, a shaggy refuge, in winter a place in the sun above the crowns of the trees.

3/6
TEXT

The ground floor is developed in relation to a thick structural element to a trunk. Among the branches of our tree are hung useful spaces: from the hanged up the laundry come across a Turkish bath, a Jacuzzi that levitates in the center of the house, with a cascade of water that falls from an impossible place.

4/6
TEXT

The boxes that contain the sauna, the toilet and the dressing room are suspended, like pieces of fruit. From inside, the fruit is seen with furry coats.

5/6
TEXT

The trunk structure twist as it ascends to the bedroom that is supported by said trunk, like resting on the crowns of the trees. It is a glass cube from which one can look over the forested watercourse, and, in the distance, Madrid.

6/6
TEXT

The construction was undertaken with different materials, as unique as the textures in the wood: stone, trunk, bark, leaves. The pixel effect of the outer layer is mixed with the shade of the trees that surrounds it.

1/6
2/6
3/6
4/6
5/6
6/6
ACADEMIE MWD DILBEEK
ACADEMY OF MUSIC, WORD AND DANCE
DILBEEK, BELGIUM
1/11
TEXT

The Academie MWD sits at a uniquely varied crossroads; South: the main square; North: Wolfsputten, a protected forest; West: CC Westrand, a Brutalist community centre; and East a series of quaint suburban villas.
Image and texture dematerialise the volume: the façade seems to blend into the forest.

2/11
TEXT

Our challenge was erecting a building with a quality of its own, which makes sense from all four directions.

3/11
TEXT

We carefully modulate scale and form: the jagged edge of the roof mimics those of the homes across the street, growing gradually to the cantilevered auditorium at the other end, and rising up to look face to face towards the monumental volumes of CC Westrand.

4/11
5/11
6/11
7/11
8/11
TEXT

The building changes dramatically as we move along the sidewalk; walking towards the forest, we see forest; walking towards the grey Westrand we see greys, whites and blue skies.

9/11
TEXT

Looking straight into the façade, we see the colours of a painting by A. Hoppenbrouwers, the architect of neighbouring Westrand.

10/11
11/11
1/7
2/7
3/7
4/7
5/7
6/7
7/7
Nobelia
High performance Low energy Building
Kigali, Rwanda
1/4
TEXT

Nobelia, 40,000 m2 mixed use, a pedestrian hub and the main entrance to the business district of Kigali, Rwanda, is the first 6-star GBC certified design in intertropical Africa.

2/4
TEXT

Its construction methods, low impact and low cost, minimize imports and create local industry with simple, lightweight and compact materials, mostly locally produced.

3/4
TEXT

It is flexible, to adapt to changing uses over time without investing more resources.

4/4
1/3
TEXT

It will use 17% of the electricity and 1% of the water compared to a standard building. It is equipped to harvest rain water, clean water on site, and purify a proportion of used water back to human-contact quality, with only a marginal loss.

2/3
TEXT

It will achieve maximum comfort with passive and active strategies: night cooling, free cooling, thermal storage, thermal inertia, careful orientation and a microclimate of climbing plants on the shaded walkways that cover the façade.

3/3
OOSTCAMPUS PARK
PRODUCTIVE LANDSCAPE
OOSTKAMP, BELGIUM
1/6
TEXT

An energy producing park, built with recycled materials. Park activities, cycle and pedestrian lanes coexist in harmony with yards for storage and the management of construction material.

2/6
TEXT

The park around the building is also built with a very controlled budget, and its features are productive systems, rather than an expense.

3/6
TEXT

The city's road work department material storage integrates with pedestrian and cycling routes. It is part of a European Interreg MP4 project: Making Places Profitable.

4/6
TEXT

Water harvesting in two steps: the roof provides clean water for all the toilets, the workshops, and the vehicle cleaning point.

5/6
TEXT

This adds to the water collected in the plot, which may contain some sand to filter, but is perfect to fill the street-cleaning truck tanks.

6/6
1/5
2/5
3/5
4/5
5/5
MAISON DU PROJET
CRADLE TO CRADLE BUILDING
ROUBAIX, FRANCE
1/13
TEXT

RMdP is the first C2C (Cradle to Cradle) building in France. A regenerator of a former factory, it is an economic, cultural and environmental activator.

2/13
TEXT

The MdP (House of the Project) hosts meetings, exhibitions, calls for tender, as needed to reactivate the 1.000 Ha area into the circular economy.

3/13
TEXT

It is also improving soil and air conditions, eating up the chemicals left over from former industrial activity.

4/13
TEXT

There were no earthworks, using driven piles that may be recovered; the structure and façades are designed for disassembly and reuse.

5/13
TEXT

Materials are biodegradable or recyclable, with zero harmful chemicals

6/13
TEXT

Sanitation generates nutrients, with the chimneys of three dry toilets as a main feature of the façade.

7/13
TEXT

Landscaping cleans the soil; the building feeds on clean energies, with controlled solar exposure and the principle of the thermal onion.

8/13
TEXT

Technology reuse is easy, the designers call it “superfurniture”: mobile equipment units to provide a specific function to any space.

9/13
10/13
11/13
12/13
13/13
1/6
2/6
3/6
4/6
5/6
6/6
DC21
APARTMENT
MADRID, SPAIN
1/3
TEXT

¿Cómo conseguir que un piso tradicional de infinitos pasillos y minúsculos dormitorios se convierta en un ambiente espacioso… pero sin renunciar a la intimidad de los dormitorios?

2/3
TEXT

La respuesta es: jugando con los techos. Todo el techo del piso es visible desde la entrada y el salón, lo que da una perspectiva amplia y convierte toda la superficie en un generoso loft. Dentro de este espacio aparecen unos muebles de madera cálida que protegen los dormitorios, estos con su propio techo a una altura más acorde con sus dimensiones. Dentro de los dormitorios, las proporciones son cómodas, y su blancura refuerza la luminosidad de las ventanas que protagonizan el espacio.

3/3
TEXT

Duplicando los techos hemos duplicado la superficie. Antes había un salón minúsculo y dormitorios estrechos, ahora hay un enorme salón, y los mismos dormitorios, pero más proporcionados.

La cocina se sitúa en un lugar estratégico, suficientemente integrada con el comedor para permitir la vida doméstica compartida, pero a la vez recogida y bien equipada para que humos y ruidos no invadan el espacio.

1/3
2/3
3/3
DEARTE
Diseño de la XIV Feria Dearte Contemporáneo
Madrid, Spain
1/2
TEXT

La superficie expositiva de la propuesta es un sencillo panel pintado de color negro mate para que la luz natural destaque al máximo las obras de la feria.

2/2
TEXT

La planta alta de LaSede del COAM es una galería acristalada, bañada en luz y con magníficas vistas de los tejados de Madrid.
La feria se recorre por el perímetro del edificio, junto a la luz y las vistas, desde donde se va accediendo a cada bahía expositiva que queda marcada por uno de los elementos singulares. De esta manera las zonas de exposición se abren a la luz natural, aunque siempre evitando la luz directa.

1/3
2/3
3/3
HORIZONTAL LOI 130
Building Complex for the European Commissions
Brussels, Belgium
1/6
TEXT

After an open call, 30 international teams were selected to design a new building complex for the European Commission in Brussels with the offices of the Commissions, as well as childcare centres, a visitor centre, restaurants shops and public spaces with green areas.

2/6
TEXT

The declared aim was to increase efficiency and reduce its environmental footprint, setting an example of sustainable construction.

3/6
TEXT

The towers are cut to maximize the allowed breadth facing Loi, but their depth is also cut at 5 degrees east of the south to optimize solar exposure through the year. This results in six façade orientations.

4/6
TEXT

Contradicting the brief, our proposal keeps the existing buildings of most recent construction, those on phase 2, which represent a substantial proportion of the requested surfaces.

5/6
TEXT

The car park runs along Rue de la Loi, on the side of the plot, not affected by the structure of the towers. It is all underground from Loi, but is accessed at mid-level from Joseph II, providing options for sectoring, and quick flows.

6/6
TEXT

Over fifty different stone and cladding varieties meet in the opaque façade, each one coming from the geological tradition of a current EU country.

1/8
TEXT

The building combines two three-dimensional façades systems depending on the direction they face. The sides oriented to south and north rely on a glass and mirror skin to let all light in, while the second system is more opaque, as it includes stone panels angled to allow views while protecting from sun exposure.

2/8
TEXT

The competition also asked for two towers, one of which was to be the tallest in Belgium, despite the location next to a low-rise residential quarter. We complied with this request but made all reasonable efforts to keep the towers slender and unobtrusive.

3/8
TEXT

We concentrated almost half the new surface in a horizontal volume, that lies above a covered public square that connects with the city and the metro.

4/8
5/8
TEXT

Pedestrians will access via the covered square, whether they are exiting from the metro, walking in from Loi, up from the bus stops on Joseph II, or through the passage from Ch. d’Etterbeek.

6/8
TEXT

This horizontal concentration of volume not only leaves the ground clear, it allows for the towers to become slimmer in the east-west direction, optimizing southern exposure and natural daylight, and minimizing its shadow on the neighborhood at the time of day when it is the longest.

7/8
TEXT

The towers have a compact core that provides the overall stability, while the perimeter is supported by relatively slender columns that stand on the cantilevered technical floors.

8/8
ERRETRES
DESIGN OFFICE
MADRID, SPAIN
1/5
TEXT

The brief required flexible workspace for a creative agency, mutable into an events area, turning into a school of design for certain months in the year, or a place to have fun - with a very limited budget. We needed a simple and light way to transform spatial arrangements.

2/5
TEXT

The agency uses honeycomb cardboard panels made from recycled paper for their presentations. We decided to use them as mobile walls, covered with a felt made from recycled plastic bottles (PET), which is sound absorbing, light, inexpensive, and good for pinning presentations on. Other panels are lined with magnetic blackboard, whiteboard, void calendars, or printed with the presentations themselves.

3/5
TEXT

The existing concrete structure and walls are all left as found, with all traces, marks and irregularities left untouched, as resulting from clearing the previously clutterd space. We simply painted everything the same shade of light grey, so that the panels with the creative work become the only feature.

4/5
TEXT

Two sets of rails define the potential spaces. The bottom rail is the duct for all the service cables, and the back of each panel is attached to it with a magnet. The panel is actually hanging from the top rail, which is painted in a stark colour.

5/5
1/3
2/3
3/3
